Main Specifications
Control /Operation Voltage 24VDC +-%20
Power Consumption 30W
Passing Block With controlled turning tripod arms positioned with 120 degrees
Tripod Locking With 24 V DC solenoids; locks when the solenoids are pulled. (In Emergency, system is shut down and turnstiles provide free passing in both directions.)
Passing Direction Control Free bi-directional entry-exit control
Tripod Position Direction Direction of the tripod position with two micro-switches.
Motion Control When the cycle starts to one direction, the reverse is blocked and after a half turn the rest of the cycle is completed, automatically and smoothly by a hydraulic shock absorber.
Installation Simple & easy installation with a special pedestal.
Operation Temperature - 20° C - + 70° C
Indicators One light indicator on both directions
Dimensions 250x850x950 mm
Weight 42 kg
Optional Accessories Drop-arm, remote control, button unit.
Steel or 304 Stainless Steel Body
Easy to Use, Bi-directional Control
Strong Ergonomic Design
Certified Quality
Continuous Service and Spare Parts Support
Turnstiles for access control
Reliable personal safety with end point locking
Versions with integrated bike interlock, waist-height gate , emergency exit function and enhanced resistance class RC
Modular combination of crossbars, roofs and guiding elements
Turnstile columns and crossbars in a range of stainless steel versions
Low energy drive and automatic adjustment of speed of rotation to match that of the person entering
Minimal power consumption
Adjustable access can be freely set in the event of power failure
Can be used under the most varied environmental conditionsc
EGW250 Waist Height Tripod Stainless Steel 90 degree
